LGBEAMER™ v8 PRO New Release

For analysis and design of complex span and loading configurations, including system design for framed openings, shearwalls, x-braces, floor joists and roof rafters:

New in Version 8:

  • 2007 NASPEC Provisions (as adopted in 2009 IBC)
  • Sheathing braced design per AISI "Wall Stud Design Standard"
  • Rafters
  • Torsion Calculator
  • HSS Sections per AISC 13th edition

Features:

  • Intuitive user-friendly interfaces
  • Analysis and Design of Cee, Channel and Zee Shapes
    • Single, boxed, back-to-back and built-up members
  • Manufacturer's Standard Section Databases
  • Uniform, concentrated, partial span and axial loads
  • Plus Integrated Design Modules for:
    • Framed Openings (Head, Sill and Jamb)
    • Shearwalls
    • X-Braces
    • Floor Joists

More Info


AISIWIN™ v8

Fast, efficient sizing for uniform bending loads, axial loads and single or multiple equal span members. "Works like an interactive version of a stud manufacturer's catalog with complete flexibility of inputs."

Features:

  • Intuitive user-friendly interfaces
  • Includes 2007 NASPEC as adopted in 2009 IBC
  • Walls (axial load-bearing or non-bearing)
  • Floors
  • Ceilings
  • Rafters
  • Span/Load Tables and Convenient Member Solver Functions
  • Headers and beams
  • Posts and Braces
  • Screw and Weld capacity
  • Deflection Track
  • Warping Torsion

More Info
